Y-STR AINE R VALVES

BRONZE Y-STR AINER
W/ BLOW OUT

Part
#BYSIsize IPS (Threaded)
#BYSCsize CxC (Sweat
Sizes: ½” – 2” Y- STRAINER VALVES
SIZE IPS CxC WEIGHTS
(INCH)
A L H L H (IPS) (C-C)
3/8" 1/4 2.36 1.81 0.36
1/2" 1/4 2.00 1.97 2.76 1.77 0.46 0.36 NO. PART MATERIAL ASTM SPEC
3/4" 1/4 3.15 2.40 3.35 2.20 0.74 0.54 1 Body Bronze B62
1" 1/2 3.70 3.03 3.78 2.80 1.12 0.84 2 Cap Brass B124
1-1/4" 1/2 4.41 3.62 4.57 3.31 1.96 1.39 3 Screen 304 Stainless Steel Commercial
1-1/2" 3/4 4.84 4.25 5.31 3.94 2.50 1.93 4 Gasket Non-Asbestos Commercial
2" 1 5.90 5.20 6.10 4.76 4.40 3.20

BRONZE Y-STR AINER SIZE L ± 0.5 B ± 2 L1 ± 0.5 C
1/4" 66.0 38.0 65.8 1/4"
Part #BYSTI 3/8" 66.0 38.0 65.8 1/4"
#BYSTC 1/2" 79.5 47.0 81.0 1/4"
3/4" 87.0 43.0 91.6 1/4"
Sizes: ½” – 2” 1" 104.5 56.5 109.0 3/8"
1-1/4" 124.5 70.0 130.5 3/8"
1-1/2" 142.0 73.0 149.0 1/2"
2" 170.0 93.5 188.0 1/2" VALVES
2-1/2" 210.0 126.0 210.0 3/4"
3" 238.0 142.5 238.0 3/4"

NO. PRINT NAME MATERIAL QTY
1 BODY BRONZE C84400 1
2 CAP BRONZE C84400 1
3 SCREEN SS-304 1
4 GASKET NON-ASBESTOS 1
5 PLUG BRASS 1

CAST IRON THRE ADED
IPS Y-STR AINER

Part #CYSTsize IPS DN DIMENSIONS (MM)
Sizes: ½“ – 3” INCH MM A B(MAX) PLUG T T1
1/4" 8 81 55 1/4" 2.4 2.4 Y- STRAINER VALVES
3/8" 10 81 57 1/4" 2.5 2.5
1/2" 15 81 70 3/8" 2.54 2.54
NO. PRINT NAME STANDARD SPECIFICATION OPTIONS
3/4" 20 95 72 3/8" 3 3
1 VALVE BODY ASTM A536, 65-45-12 1
1" 25 102 78 1/2" 4.06 4.06
2 SCREEN AISI 304 1
1 1/4" 32 127 92 1/2" 4.83 4.83
3 SEALING GRAPHITE + 1 1 1/2" 40 146 118 1/2" 4.83 4.83
WASHER ACANTHOPORE PLATE
2" 50 117 120 1/2" 5.59 5.59
4 COVER ASTM 536, 65-45-12 1
2 1/2" 65 234 136 3/4" 5.59 5.59
5 PLUG MALLEABLE IRON 1
GALVANIZED 3" 80 254 150 3/4" 5.59 5.59
